Systemicon Abgassysteme einwandig
Temperature up to 1400°F
Pressure in inch
Gas
Oil
Solid fuels
Wet operation mode
Single wall
Limited lifetime warranty
Jeremias® Exhaust Systems
    2. Commercial Exhaust Systems
    3. Single wall systems
    4. SWAF

    SWAF

    Single Wall All Fuel Exhaust System

    Single Wall All Fuel Exhaust System:
    Easiest and Fastest joint assembly on the market using innovative and industry first technology

    SYSTEM_DETAIL_ICONS

    Product description

    Main features

    • Factory CAD designs for installation ease
    • 100% Stainless-Seel with maintenance-free Limited lifetime Warranty

    Applications

    • Boiler Stack for commercial / industrial boilers or appliances that do not exceed 1400°F flue gas temperatures
    • Special Gas Vent for condensing boilers and water heaters

    Technical specifications

    Material

    444 or 316L stainless-steel

    All Supports and accessories are stainless-steel

    Diameter6 - 36"
    Connection2.2" overlapping joint with patented light-weight technology, and double female socket peritting fastest alignment/installation on the market.
    1. Use supplied silicone sealant to make the complete seal.
    2. Push the male/female ends together
    3. Install the outer locking band to ensure correct engagement
    SWAF

    UL Listings (and ULC)


    UL-1978 Standard
    Grease Duct
    (ULC-S662 Standard for Factory-Built Grease Ducts)

    UL-103 Standard
    Building Heating Appliance Chimney
    (Industrial Type 540°C Chimney)

    UL-1738 Standard, Venting Systems for Gas-Burning Appliances, Categories II, III & IV
    (ULC-S636 Standard for Type BH Gas Venting Systems
