Systemicon Edelstahlschornstein doppelwandig
Gas
Solid fuels
Wet operation mode
Temperature up to 470°F
Negative pressure
Double wall
Limited lifetime warranty
Jeremias® Exhaust Systems
    2. Commercial Exhaust Systems
    3. Double wall systems
    4. ECCO Type B Gas Vent

    ECCO Type B Gas Vent

    Exhaust for Category I Appliances Only

    Double Wall Type B Gas Vent

    SYSTEM_DETAIL_ICONS

    Product description

    Applications

    • ECCO Type B Gas Vent and accessories are for venting listed Natural Gas or Propane Category I. or appliances equipped with a draft hood.
    • ECCO Type B Gas Vent may be used on other gasburning appliances, provided the appliance is certified for use with Type B Gas Vent, the installation conforms to the appliance installation instructions, and the installation is acceptable to the requirements of the local authority having jurisdiction.

    Technical specifications

    Material

    Inner liner made of Aluminum Alloy

    Outer Jacket MaterialOuter jacket made of Galvalume Steel
    Insulation

    Insulating air space

    ¼” on diameters 3” through 8”
    1”  on diameters 10” through 30”

    Inner diameter

    3 - 12 inch
    10 - 30 inch

    Ratings/ Installation Requirements

    Maximum 470°F continuous flue gas temperature

    Negative vent pressures only

    Install at ¼” per foot slope back towards appliance

    InsulationInsulating air space
    3" through 8" Connection DetailsAlign the seams and twist left to lock
    10" through 30" Connection DetailsInsert the male coupler into the female coupler and use sheet metal screws through holes in the female coupler
    ECCO Type B Gas Vent

    UL Listings (and ULC)


    UL-441 Standard, Gas Vents

    ULC-S605 Standard for Gas Vents
